YMC-Pack Diol
YMC-Pack Diol Analytical HPLC Columns
The silica-based YMC-Pack Diol is a rugged and efficient normal phase, reversed phase or size exclusion material. It is generally used for the separation of biomolecules and pharmaceuticals. As the non-specific adsorptive sites have been eliminated it exhibits better performance characteristics for size separations than nonbonded silica.
YMC-Pack Diol is available in four tightly controlled porosities and is, therefore, suitable for separation and molecular weight determination of a wide range of peptides, proteins, oligonucleotides, carbohydrates and other biopolymers with molecular weights of approx 200 to several hundred thousand.
- Buy
- Features
-
- Applicable to proteins, peptides, carbohydrates and nucleic acid components
- 2 µm for UHPLC
- Scalability from 2 or 3 µm to 20 µm
- Reproducibility with minimal secondary interactions
- Specifications
-
YMC-Pack Diol-60 YMC-Pack Diol-120 YMC-Pack Diol-200 YMC-Pack Diol-300 Suitable for carbohydrates and peptides intermediate proteins large proteins very large proteins/monoclonal antibodiesRecommended MW range <10,000 Da 1,000 –100,000 Da5,000 –300,000 Da20,000 –1,000,000 DaPore size 6 nm / 60 Å 12 nm / 120 Å 20 nm / 200 Å 30 nm / 300 Å Particle size 3, 5 µm 3, 5 µm 2, 3, 5 µm 2, 3, 5 µm Surface area 650 m2/g 330 m2/g 175 m2/g 100 m2/g Recommended pH Range 5 - 7.5 - Literature
-
-
YMC General Catalogue
Contains information on the full range of YMC columns
-
YMC Analytical Column Overview
Specifications of the full range of YMC columns
-
