CP-Wax

CP-WAX GC Columns from Agilent Technologies

A wide variety of Agilent J&W CP-Wax GC columns are available for specific applications.

CP-Wax 51 for Amines - analyzes C4-C10 amines, diamines and aromatic amines to EPA method 607
CP-Wax 52 CB - provides higher resolution of low boiling point analytes, and is ideal for a variety of EPA and ASTM methods
CP-Wax 57 CB - unique selectivity, especially for the analysis of alcohols in the brewing and wines/spirits industry
CP-Wax 57 for Glycols and Alcohols - provides consistent column inertness performance to ensure sensitivity, performance and integrity in trace analysis
CP-Wax 58 FFAP CB - designed for acidic compounds such as phenols and free fatty acids, both derivatized and underivatized
CP-Wax for Volatile Amines and Diamines - delivers symmetrical peaks with C3-C8 amines and diamines due to basic reagent deactivation

CP-Wax All pictures shown are for illustration purpose only. Actual product may vary.

Buy

Features

CP-Wax 51 for Amines GC Columns

Agilent J&W CP-Wax 51 for Amines is designed for the analysis of C4-C10 amines, diamines and aromatic amines. The column conforms to EPA method 607.

For the analysis of C4-C10 amines, diamines and aromatic amines
Conforms to EPA 607
Symmetrical peaks due to basic reagent deactivation

CP-Wax 52 CB GC Columns

CP-Wax 52 CB GC columns have lower minimum temperature and a higher maximum temperature than non-bonded polyethylene glycol (PEG) columns due to extensive cross linking, delivering higher resolution of low-boiling-point analytes. With guaranteed reproducibility and excellent temperature stability, CP-Wax 52 CB is ideal for EPA and ASTM methods.

The improved line of Agilent J&W CP-Wax 52 CB GC columns utilizes the same innovative inert processes employed in the manufacture of Agilent J&W DB-WAX Ultra Inert columns. These columns have an extended inertness lifetime that withstands repeated temperature cycling to the upper temperature limits of the column, while critical performance parameters such as selectivity, theoretical plates and retention indices remain unchanged.

Polyethylene glycol (PEG) phase
High polarity - provides separations for a broad range of applications
Excellent column-to-column inertness reproducibility
Sharp and symmetrical peak shape performance for active polar compounds
Bonded and cross-linked; solvent rinsable
Wider temperature range than non-bonded polyethylene glycols
High resolution of low boiling point analytes
Excellent temperature stability for a variety of EPA and ASTM methods

Similar Phases: SUPELCOWAX 10, SUPEROX II, Stabilwax, BP-20, 007-CW, Carbowax, Rtx-WAX, ZB-WAX, ZB-WAXPlus

CP-Wax 57 CB GC Columns

Agilent J&W CP-Wax 57 CB has a unique selectivity, especially for the analysis of alcohols in the brewing and wines/spirits industry. The high inertness of this column offers excellent peak shapes for these very polar compounds, ensuring high precision. The 0.15 mm id version offers a significant gain in analysis speed.

Unique high polarity bonded wax column
Industry proven for the analysis of alcohols in the brewing and wine/spirits industry
Excellent inertness for optimum peak shape of alcohols and glycols
Offered in 0.15 mm id for significantly high speed throughput
Improved signal-to-noise ratio for better sensitivity and mass spectral integrity
Bonded and cross-linked; solvent rinsable

Similar Phases: SUPELCOWAX 10, SUPEROX II, CB-WAX, Stabilwax, BP-20, 007-CW, Carbowax, Rtx-WAX, ZB-WAX

CP-Wax 57 CB for Glycols and Alcohols GC Columns

Agilent J&W CP-Wax 57 CB for Glycols and Alcohols is optimized for the analysis of glycols, diols and alcohols. It has a unique, high polarity wax phase that produces symmetrical peaks. The cross-linked and bonded phase delivers robustness and enhanced column lifetime.

Optimized for the analysis of glycols, diols and alcohols
Unique, high polarity wax phase
Symmetrical peaks providing the most accurate results
Cross-linked and bonded phase delivers robustness and enhanced column lifetime

CP-Wax 58 FFAP CB GC Columns

Agilent J&W CP-Wax 58 FFAP CB column is a nitroterephthalic acid-modified, chemically bonded polyethylene glycol phase. It is designed for the analysis of acidic compounds, such as phenols, and underivatized as well as derivatized free fatty acids.

Nitroterephthalic acid-modified polyethylene glycol phase
High polarity
Ideal for analysis of acidic compounds, such as phenols, underivatized and derivatized free fatty acids
Highest polarity bonded wax column for analyzing polar compounds
Chemically-bonded
Solvent rinsable
High inertness provides excellent peak shape

Similar Phases: SUPELCOWAX 10, SUPEROX II, CB-WAX, Stabilwax, BP-20, 007-CW, Carbowax, Rtx-WAX, ZB-WAX

CP-Wax for Volatile Amines and Diamines GC Columns

Agilent J&W CP-Wax for Volatile Amines and Diamines is optimized for analysis of volatile amines and diamines, particularly C3-C8 amines and diamines. The column delivers symmetrical peaks due to basic reagent deactivation and exhibits good inertness towards basic compounds.

Guaranteed analysis of volatile amines and diamines
Symmetrical peaks due to basic reagent deactivation
Good inertness towards basic compounds

Specifications

CP-Wax 52 CB Temperature Specifications

ID (mm)	0.10 mm	0.15 - 0.32 mm	0.53 mm	0.53 mm (UltiMetal)
Length (m)	10 m	10 - 60 m	10 - 100 m	10 - 50 m
Film (µm)	0.10 - 0.20 µm	0.12 - 1.20 µm	1.00 - 2.00 µm	1.00 - 2.00 µm
Temperature Limits (°C)	20 – 250/265 °C	20 – 250/265 °C	20 – 250/265 °C	20 – 250/275 °C

CP-Wax 57 CB Temperature Specifications

ID (mm)	0.15 – 0.32 mm	0.53 mm
Length (m)	25 - 60 m	25 m
Film (µm)	0.12 – 1.20 µm	1.00 - 2.00 µm
Temperature Limits (°C)	20 - 200/225 °C	20 - 200/225 °C

CP-Wax 57 CB for Glycols and Alcohols Temperature Specifications

ID (mm)	0.25 mm	0.53 mm
Length (m)	25 m	25 m
Film (µm)	0.20 µm	0.50 µm
Temperature Limits (°C)	200/200 °C	225/250 °C

CP-Wax 58 FFAP CB Temperature Specifications

ID (mm)	0.20 – 0.32 mm	0.53 mm
Length (m)	25 – 50 m	15 - 50 m
Film (µm)	0.20 – 1.20 µm	0.50 - 2.00 µm
Temperature Limits (°C)	20 - 250/275 °C	20 - 250/275 °C

CP-Wax for Volatile Amines and Diamines Temperature Specifications

ID (mm)	0.32 mm	0.53 mm
Length (m)	25 m	25 m
Film (µm)	1.20 µm	2.00 µm
Temperature Limits (°C)	220/220 °C	220/220 °C
